Product Overview
The Waterproof 12+12 RGB LED Strobe Light combines powerful strobing effects with weather-resistant construction, designed for both indoor and outdoor entertainment applications. This rugged fixture features two banks of 12 high-output RGB LEDs (total 24 LEDs) that deliver intense strobing effects with full color control, producing vibrant flashes that cut through ambient light in any environment. Unlike conventional strobes limited to white light and indoor use, this waterproof model offers IP65 protection alongside RGB color mixing, enabling dynamic colored strobe effects in rain, dust, and temperature extremes from -20°C to 50°C. With versatile control options and robust build quality, it's engineered for festivals, outdoor concerts, and any event requiring reliable strobing effects in challenging conditions.
Product Features
Dual-Bank RGB LED Configuration
The fixture features a unique dual-bank design with 12+12 high-brightness RGB LEDs arranged in two separate arrays that can operate in synchronization or independently. Each LED delivers 15W of output, with the entire fixture producing a total power output of 360W and peak light output of 28,800 lumens for intense strobing effects visible even in daylight conditions. The advanced RGB mixing system creates over 16 million color combinations, with each bank supporting independent color programming for complex multi-color strobe patterns.
Weatherproof Construction
Built for outdoor durability, the fixture achieves an IP65 ingress protection rating that shields internal components from dust, rain, and splashing water. The housing is constructed from corrosion-resistant aluminum alloy with a sealed front bezel and tempered glass lens that resists impact and UV damage. All electrical connections use waterproof locking connectors, and the internal circuitry includes moisture protection to prevent condensation issues in temperature-variable environments.
Versatile Strobe Control
The strobe system offers precise control over flash parameters, including adjustable speed from 1-25 flashes per second, variable duration from 10ms-200ms, and intensity control from 0-100%. Control options include DMX512 protocol (12/24 channel modes), sound activation with adjustable sensitivity, and stand-alone mode with 15 built-in programs. The 24-channel DMX mode provides independent control of each LED bank's color, speed, and duration parameters for advanced programming.
Rugged Performance Features
Engineered for demanding environments, the fixture includes a heavy-duty mounting bracket with 360° rotation capability for flexible positioning, and a safety cable attachment point for secure installation. The advanced cooling system uses convection heat dissipation supplemented by weatherproof fans that maintain optimal operating temperatures without drawing in moisture. The fixture weighs 15.3 kgs and operates on a universal voltage range of AC 100-240V, 50/60Hz with surge protection up to 6kV.
Product Applications
Outdoor Music Festivals
At outdoor music festivals, this waterproof strobe delivers powerful colored strobe effects that enhance stage productions regardless of weather conditions. Its IP65 rating ensures reliable operation in rain or dusty environments, while the high-output LEDs produce visible flashes even during daylight hours. Multiple units can be positioned around stages to create synchronized strobing across performance areas.
Poolside and Beach Events
For pool parties, beach concerts, and waterfront events, the fixture provides safe, weather-resistant strobe effects that complement aquatic environments. The waterproof design allows installation near water without risk of damage, while the RGB color capabilities create dynamic lighting that reflects off water surfaces for enhanced visual impact.
Theme Parks and Outdoor Venues
Theme parks and permanent outdoor venues benefit from the fixture's durable construction and low maintenance requirements. It can be integrated into outdoor stage shows, parade floats, or scenic installations, withstanding exposure to elements year-round while delivering consistent strobe effects. The wide temperature tolerance ensures operation in both hot and cold climates.
Industrial and Architectural Events
At industrial spaces, warehouses, and architectural installations, the fixture's rugged design fits seamlessly into raw environments while delivering impactful lighting effects. It can highlight structural elements during events, provide synchronized strobing for product launches, and create dynamic lighting for outdoor movie nights and drive-in events, withstanding the vibrations and conditions of industrial settings.
FAQ
What does the IP65 rating mean for practical use?
An IP65 rating means the fixture is completely protected against dust ingress and low-pressure water jets from any direction, making it suitable for outdoor use in rain, snow, and dusty environments. It can withstand direct rainfall but is not designed for submersion in water. This level of protection ensures reliable operation in typical outdoor event conditions without requiring additional weather protection measures.
How fast can the strobe flash and what patterns are possible?
The fixture offers adjustable strobe speeds from 1 flash per second (slow pulse) up to 25 flashes per second (rapid strobing), with flash duration adjustable from 10ms (quick pulses) to 200ms (longer bursts). Possible patterns include synchronized flashing, alternating bank flashes, color-morphing strobes, chase patterns between banks, and sound-triggered flashes that respond to music beats and audio peaks.
What is the effective coverage area?
Each LED features a 30° beam angle that creates focused intensity while ensuring sufficient overlap between diodes for uniform coverage. At a distance of 10 meters, each fixture covers an area of approximately 28 square meters with consistent strobe intensity. The dual-bank design allows for wider coverage when positioned with banks angled slightly apart, or more intense coverage when focused on the same area.
How many fixtures can be connected in a daisy-chain?
When using DMX512 control, up to 16 fixtures can be reliably daisy-chained using standard DMX cabling, provided the total cable length does not exceed 100 meters. For power daisy-chaining, up to 3 fixtures can be connected on a single 15A circuit using the optional waterproof power linking cables, with each fixture consuming 360W at full power.
How is the fixture maintained in outdoor environments?
The fixture requires minimal maintenance despite outdoor use. Periodic inspection of cable connections is recommended to ensure waterproof seals remain intact. The front lens can be cleaned with a soft cloth and mild detergent to remove dust or water spots. The LEDs have a rated lifespan of 50,000 hours under normal operating conditions, and the weatherproof fans feature sealed bearings designed for 30,000+ hours of maintenance-free operation.
Voltage: AC100~240V 50/60HZ
Power: 500W
Lamp beads: 1440 RGB+W, 12+12 segments
Control method: DMX512、 Self driving, master-slave, voice control, with RDM function.
Channel: CH4、CH16、CH48
Dimming: 32-bit 0~100% linear dimming
Features: Flash+Staining+Effect
Working temperature: -30 ° C~50 ° C
Strobe frequency: 1~30HZ
Appearance: Metal, Black
Connection method: DMX512 input/output/power input/output.
IP rating: IP20
Lamp size: 64 X 25X 28CM
Net weight of lighting fixtures: 13.4KG
One pack of 6 aviation cases size: 107 X68 X56 CM
Empty weight of aviation container 30 Kg
